High Efficiency Sandwich Panel Roll Forming Machine with Thickness 30-300mm

High Efficiency Sandwich Panel Roll Forming Machine with Thickness 30-300mm

Thickness 30-300mm Sandwich Panel Roll Forming Machine

13 Stations EPS Sandwich Panel Machine

100mm Diameter Shafts Rock Wool Sandwich Panel Machine

Nom de marque:

FMS

Model Number:

FMS-sandwich

Nous contacter
Demandez un devis
High Efficiency Sandwich Panel Roll Forming Machine with Thickness 30-300mm High Efficiency Sandwich Panel Roll Forming Machine with Thickness 30-300mm High Efficiency Sandwich Panel Roll Forming Machine with Thickness 30-300mm High Efficiency Sandwich Panel Roll Forming Machine with Thickness 30-300mm High Efficiency Sandwich Panel Roll Forming Machine with Thickness 30-300mm
Détails du produit
Usage:
Isolation
Épaisseur de plaque latérale:
16 mm
Diamètre des arbres:
100 mm
Épaisseur:
50-300
Étapes de formation:
13 stations
Marque motrice:
Lichao
Vitesse:
1 à 6 m/min
Puissance hydraulique de moteur:
32 kW
Mettre en évidence:

Thickness 30-300mm Sandwich Panel Roll Forming Machine

,

13 Stations EPS Sandwich Panel Machine

,

100mm Diameter Shafts Rock Wool Sandwich Panel Machine

Conditions de paiement et d'expédition
Quantité de commande min
1
Prix
25000-50000usd
Détails d'emballage
Nu
Délai de livraison
40
Conditions de paiement
T / t
Capacité d'approvisionnement
1000
Produits connexes
Un bon prix. Mode EPS Sandwich Panel Line for 50-300 Thickness Production Customization en ligne

Mode EPS Sandwich Panel Line for 50-300 Thickness Production Customization

Obtenez le meilleur prix
Un bon prix. Eps Rock And Wool Sandwich Panel Production Machine For Customer Requirements en ligne

Eps Rock And Wool Sandwich Panel Production Machine For Customer Requirements

Obtenez le meilleur prix
Un bon prix. 32KW Hydraulic Motor Power Sandwich Panel Roll Forming Machine with Thickness 50-300mm en ligne

32KW Hydraulic Motor Power Sandwich Panel Roll Forming Machine with Thickness 50-300mm

Obtenez le meilleur prix
Un bon prix. High Efficiency Sandwich Panel Roll Forming Machine with Thickness 30-300mm en ligne

High Efficiency Sandwich Panel Roll Forming Machine with Thickness 30-300mm

Obtenez le meilleur prix
Nous contacter
86-317-2016816
Contactez-nous maintenant
Description du produit
Thickness 30-300mm Rock Wool And Eps Foam Sandwich Panel Integrated Machine With High Speed
Product Description
The Sandwich Panel Roll Forming Machine is an essential piece of equipment for the production of EPS sandwich panels, specifically designed to create sandwich roof panels and wall panels with high efficiency and precision.
Key features include:
  • Advanced transmission system with gears and sprockets for smooth, reliable operation
  • Versatile thickness range of 50-300mm for various insulation requirements
  • Cr12 heat-treated blades for durability and precise cutting with clean edges
  • 100mm diameter shafts for stability and continuous production capability

  • High Efficiency Sandwich Panel Roll Forming Machine with Thickness 30-300mm 0

Technical Parameters
Parameter Specification
Forming Steps 13 Stations
Thickness 50-300mm
Control PLC Control System
Diameter Of Shafts 100mm
Cutting Mode Hydraulic Guide Column
Roller Cr15
Speed 1-6m/min
Hydraulic Motor Power 32KW
Material Of Blade Cr12 Heat Treatment
Roller Material Cr12
Applications
This versatile machine is ideal for producing various sandwich panels for construction applications, including:
  • Sandwich roof panels
  • Wall panels
  • Rock wool sandwich panels
  • Residential and commercial building panels
The machine features a reliable gear/sprocket transmission system and Lichao motor brand for optimal performance in production lines.
Support and Services
Comprehensive technical support is available, including:
  • Installation assistance
  • Troubleshooting support
  • Maintenance guidance
  • Detailed product manuals and training materials
Frequently Asked Questions
Q: What is the brand name of this Sandwich Panel Roll Forming Machine?
A: The brand name is FMS.
Q: What is the model number of this machine?
A: The model number is FMS-sandwich.
Q: Where is this Sandwich Panel Roll Forming Machine manufactured?
A: It is manufactured in China.
Q: What type of panels can be produced using this machine?
A: This machine can produce a variety of sandwich panels, including those with different core materials and thicknesses.
Q: Is technical support available for this machine?
A: Yes, technical support is provided by the manufacturer to assist with any inquiries or issues related to the machine.
Contact via WhatsApp: +8617736986169
